7,200.00 QAR
3 Years Warranty
7 Years warranty for Compressor
Split and Floor Standing AC price includes Standard installation
With a 5 meter pipe Kit. Additional piping will be with additional extra charges
For Floor Standing:
3Ton – 5Ton 85 QAR per meter
Outdoor bracket for floor stand 200 QAR.
You must be logged in to post a review.
| Model | OXF G60CGR EA41 | |||
| Power supply | V,Hz,Ph | 380-415V,3Ph,50Hz | ||
| Cooling（T1） | Capacity | Btu/h | 54000 | |
| Input | W | 4520 | ||
| Rated current | A | 8.00 | ||
| EER | Btu/h/W | 11.947 | ||
| Cooling（T3) | Capacity | Btu/h | 48000 | |
| Input | W | 5550 | ||
| Rated current | A | 9.32 | ||
| EER | Btu/h/W | 8.649 | ||
| Heating | Capacity | Btu/h | / | |
| Input | W | / | ||
| Rated current | A | / | ||
| COP | W/W | / | ||
| Max. input consumption | W | 7000 | ||
| Max. current | A | 13 | ||
| Starting current | A | 64 | ||
| Compressor | Model | ZP61KCE-TFD-52E | ||
| Type | SCROLL | |||
| Brand | Copeland | |||
| Capacity | Btu/h | 50156 | ||
| Input | W | 4750 | ||
| Rated current(RLA) | A | 8.3 | ||
| Locked rotor Amp(LRA) | A | 64 | ||
| Thermal protector | / | |||
| Thermal protector position | INTERNAL | |||
| Capacitor | uF | / | ||
| Refrigerant oil/oil charge | ml | POE/1656 | ||
| Indoor fan motor | Model | ZKFN-200-8-1 | ||
| Type | DC | |||
| Input | W | 210 | ||
| Output | W | 200 | ||
| Capacitor | uF | / | ||
| Speed(Turbo/Hi/Lo) | r/min | 600/530/480 | ||
| Indoor coil | a.Number of rows | 3.0 | ||
| b.Tube pitch(a)x row pitch(b) | mm | 25.4x22 | ||
| c.Fin spacing | mm | 1.4 | ||
| d.Fin type (code) | Hydrophilic aluminum | |||
| e.Tube outside dia.and type | mm | Φ9.52,Inner groove tube | ||
| f.Coil length x height x width | mm | 484x813x66 | ||
| g.Number of circuits | 6 | |||
| Indoor air flow (Turbo/Hi/Lo) | m3/h | 2280/2050/1950 | ||
| Indoor noise level (Turbo/Hi/Lo) | dB(A) | 57/54/53 | ||
| Indoor unit | Dimension(W*D*H) | mm | 610x390x1925 | |
| Packing (W*D*H) | mm | 765x515x2070 | ||
| Net/Gross weight | Kg | 56.7/76.1 | ||
| Outdoor fan motor | Model | YKT-90-6-10+YKT-90-6-10 | ||
| Type | AC | |||
| Input | W | 142 | ||
| Output | W | 90 | ||
| Capacitor | uF | 5 | ||
| Speed | r/min | 880 | ||
| Outdoor coil | a.Number of rows | 3 | ||
| b.Tube pitch(a)x row pitch(b) | mm | 21x13.37 | ||
| c.Fin spacing | mm | 1.3 | ||
| d.Fin type (code) | Hydrophilic aluminum | |||
| e.Tube outside dia.and type | mm | Φ7,Inner groove tube | ||
| f.Coil length x height x width | mm | 985x1260x40.11 | ||
| g.Number of circuits | 14 | |||
| Outdoor noise level | dB(A) | 61 | ||
| Outdoor unit | Dimension(W*D*H) | mm | 952x415x1333 | |
| Packing (W*D*H) | mm | 1095x495x1480 | ||
| Net/Gross weight | Kg | 112.6/126.6 | ||
| Refrigerant type | g | R410A/3.8 | ||
| Design pressure | MPa | 4.8/1.5 | ||
| Refrigerant piping | Liquid side/ Gas side | mm(inch) | 9.52(3/8")/22(7/8") | |
| Max. refrigerant pipe length | m | 50 | ||
| Max. difference in level | m | 30 | ||
| Connection wiring | 4x1.5 | |||
| Plug type | 5x2.5 | |||
| Thermostat type | Remote Control | |||
| Operation temperature | ℃ | 17~30 | ||
| Room temperature | Indoor(cooling/ heating) | ℃ | 17～32/-- | |
| Outdoor(cooling/heating) | ℃ | 18～52/-- | ||
| Application area |
| 73-107 | ||
